Suitable for packaging of all kinds of objects with regular solid state, such as biscuits bread, speed wheaten food, moon cake, candy, medicines, daily necessities, etc.
It adopts original single servo or double servo motor control, which is more intelligent than other similar inverter motors or inverter controlled products at home and abroad, with higher packaging precision, wider adjustable range, more precise control and lower scrap rate. Better stability. Thanks to the world��s leading fully open box structure, the transmission structure is clear at a glance, and maintenance is more convenient;
1.Compact structure, stable function and Simple operation.
2.The first third-generation double frequency control the bag could be set and cut, unnecessary adjust air without changing film color code tracking one pace reachs the designated position, il��s saving lime and film.
3.It adopts imported electric appliance, touch man machine interface, conv-enient parameter setting.
4.Self-cheching function, trouble can be read easily.
5.High sensor photoelectric color chart tracking, make the cutting position more correctly.
6.Dependant temperature PID controlling suitable for various mate-ria I sof packaging membrane.
7.Position stop function, no adhesive and no waste of membrane.
8.Ciean rotation system, more reliable operation and more convenient maintenance.
9.All the controlling operates by the software, convenience for function adjustment and technical up grading.

Model	KD-260	KD-350	KD-450
Length of bags	60-200mm	60-250mm	60-300mm
Packaging width	25-100mm	50-150mm	50-200mm
Packaging high	5-45mm	5-50mrri	10-80mm
Intensity of sealing (N/mm)	>15N mm2	>15N mm2	>15N mm2
Packaging speed	40-250packa/min	40-250packa/min	40-250packa/min
Total power	220V、50Hz、2.4Kw	220Vs SOHz、2.7Kw	220V、50Hz、2.7Kw
Overall dimensions	4100x950x1500mm	4100x1000x1500mm	4100x1050x1500mm
Weight	550kg	600kg	680kg
Max film width	260mm	350mm	450mm
Max Packaging capacity	20-250次/分	20-22CW分	20-20CW分
Suitable film thickness	0.03-0.06mm	0.03-0.06mm	0.03-0.06mm

The quality and performance of the equipment are constantly improved. The appearance, technical parameters and features of the machine are subject to change without prior notice
