HY-800
Round corner four side sealing packaging machine
PRODUCT PARAMETERS
Introduction
Technical parameter
Flow Path
Sample
Pro Details
Pro Video
<
>

1. This machine is an automatic warm baby production and packaging line with independent intellectual property rights
2. This machine can complete the functions of warm pasting fan material sealing, flattening, exhaust, single-chip packaging, printing date counting, etc. it can also be connected to the back-end 10 Piece bagging pillow machine!
2. This production line has a high degree of automation, which can greatly improve production efficiency and save labor cost!
3. The machine adopts reciprocating heat sealing plate to heat seal the roller. The sealing effect is better and more stable
4. This line can also be equipped with packing equipment to form a complete set of production line
model HY-800
Bag Size L100-400mm, w80-200mm, designed as required
Packaging film width 400-800mm
Inner core size of film roll and paper roll φ 70-75mm roll film diameter less than or equal to 380mm
Production speed 100-150bags / min depends on the package and size
supply voltage 380V50Hz3. 5kw
packaging PE / OPP PE / Pet paper film, aluminized film, pure aluminum film and other composite films
Working pressure 0.6-1.0Mpa
Machine weight 1200kg
volume four thousand and five hundred × one thousand and five hundred × 1800mm(L*W*H)

The quality and performance of the equipment are constantly improved. The appearance, technical parameters and features of the machine are subject to change without prior notice
